Victron Orion IP67 12/24-50A (1200W) DC to DC Converter Non Isolated ORI122421226

Save $259.88
Victron EnergySKU: ORION IP67 12/24-50A (1200W)
No reviews

Price:
Sale price$385.07 Regular price$644.95

Description

Victron Orion IP67 12/24-50A (1200W) DC to DC Converter Non Isolated ORI122421226, 5 Year Warranty. Completely encapsulated: waterproof, shockproof and ignition protected
Water, oil or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminium and the electronics are moulded in resin.

Completely encapsulated: waterproof, shockproof and ignition protected:

Water, oil or dirt will not damage the Orion IP67 DC-DC Converter. The casing is made of cast aluminium and the electronics are moulded in resin.

Extra-long input and output cables:

Thanks to the cables of 1.8 meters in length, intermediate cable interconnections to increase length even more will in most cases not be needed. This is an important reliability increasing feature in an area were IP67 protection grade is needed.

Wide input voltage range:

With 15 to 40 Volts input range, a stable output is ensured during surges or sags due to other equipment connected to same battery.

Protected against overheating:

It can be used in a hot environment such as a machine room.



SKU ORI122421226
Barcode 8719076048534
Brands Victron
Amps 50.0 Amps
DC Input Voltage 10-15VDC
DC Output Voltage 24V +/- 3%
Rating (A) 50A
Operating Temperature Range -40 to +70°C (full rated output up to 40°C)
Overload protection Hiccup mode, recovers automatically after fault condition is removed
Short circuit protection Yes
Protection category IP67
Efficiency 96%
Dimensions 340mm x 127mm x 63mm
Net Weight (kg) 3.0 Kg
Manufacturers Warranty 5 Year Warranty
